LEDs: difference between common anode and common cathode?
Common Anode and Common Cathode seven segment display “Arduino project for beginners”
Common Anode and Common Cathode 7-Segment Displays"Arduino Project for Beginners"Electronics (YouTube)
Checking if 7-Segment display is common Anode or Cathode
7-Segment LED Displays 101 - How To Make One Work
How to use seven segment LED display with Arduino
7 Segment Display (good information)
9v to 5v Converter – 4 Simple circuits
ECG3052 - 7-Segment display I found in a surplus store
CL10016AS- 7-Segment display I purchased online
| Pin Number | Pin Name | Description |
|---|---|---|
| 1 | e | Controls the left bottom LED of the 7-segment display |
| 2 | d | Controls the bottom most LED of the 7-segment display |
| 3 | Com |
Connected to Ground/Vcc based on type of display
common cathode: connect to GND common anode: connect to Vcc (+5V typically) |
| 4 | c | Controls the right bottom LED of the 7-segment display |
| 5 | DP | Controls the decimal point LED of the 7-segment display |
| 6 | b | Controls the top right LED of the 7-segment display |
| 7 | a | Controls the top most LED of the 7-segment display |
| 8 | Com |
Connected to Ground/Vcc based on type of display
common cathode: connect to Vcc (+5V typically) common anode: connect to GND |
| 9 | f | Controls the top left LED of the 7-segment display |
| 10 | g | Controls the middle LED of the 7-segment display |
